Implant Express Ø3.3 – Ø5.0
Global implant solution in four diameters and four lengths.
Prices on request — contact us for a tailored quotation.
The Implant Express is designed to allow placing the implant on a previously toothless ridge, even immediately after extraction. Made from Grade V titanium alloy, fully threaded with fine deep threads and a micro-thread at the base preventing bone loss, with a 2.5 mm internal hexagonal connection. Osteotec© surface treatment: fully biocompatible and osseo-conductive µ-blasting (sandblasting) that achieves the roughness levels needed for optimal osseointegration, the highest surface purity and a higher Bone-to-Implant Contact (BIC) success rate. Each implant is sterilised with gamma rays and packed individually in a sterile tube inside a sealed blister. BRAT products are CE certified and the company is ISO 13485 certified.
Specifications
- Material
- Grade V titanium alloy Ti 6Al 4V ELI
- Connection
- 2.5 mm internal hexagon
- Surface
- Osteotec© µ-blasted
- Diameters
- Ø3.3 · Ø3.75 · Ø4.2 · Ø5.0
- Lengths
- 8 · 10 · 11.5 · 13 mm
- Colour code
- Ø3.3 yellow · Ø3.75 red · Ø4.2 blue · Ø5 green
Key features
- Safe, often simplified surgical procedures
- Immediate implant placement, post extraction
- Placement in soft bone (type D4)
- Maxillary and mandibular implants with little bone depth or in the sinus floor
- Immediate loading is possible (excellent primary stability)
Implant Express color code & references
| Ø (mm) | L 8 mm | L 10 mm | L 11.5 mm | L 13 mm | Size A | Size B |
|---|---|---|---|---|---|---|
| Ø 3.3 (yellow) | E3308 | E3310 | E3311 | E3313 | 3.8 mm | 3.3 mm |
| Ø 3.75 (red) | E3708 | E3710 | E3711 | E3713 | 3.8 mm | 3.6 mm |
| Ø 4.2 (blue) | E4208 | E4210 | E4211 | E4213 | 4.2 mm | 3.91 mm |
| Ø 5.0 (green) | E0508 | E0510 | E0511 | E0513 | 5 mm | 4.61 mm |
