Implant Express Narrow Ø2.9
Narrow implant for thin crests or between close teeth.
Prices on request — contact us for a tailored quotation.
The Implant Express Narrow by BRAT is mainly used for narrow crests or between two close teeth. Fine, deep threads give important primary stability in spongy bone, a micro-thread at the base prevents bone loss and the 2 mm internal hexagon locks the abutment perfectly. Osteotec© surface treatment: fully biocompatible and osseo-conductive µ-blasting (sandblasting) that achieves the roughness levels needed for optimal osseointegration, the highest surface purity and a higher Bone-to-Implant Contact (BIC) success rate.
Specifications
- Material
- Grade V titanium alloy Ti 6Al 4V ELI
- Connection
- 2 mm internal hexagon
- Surface
- Osteotec© µ-blasted, fully threaded
- Bone types
- D1 – D4
- Packaging
- Individually sterile (gamma), double barrier tube + blister
Key features
- Safe, often simplified surgical procedures
- Immediate implant placement, post extraction
- Placement in soft bone (type D4)
- Maxillary and mandibular implants with little bone depth or in the sinus floor
- Immediate loading is possible (excellent primary stability)
References — length & diameter
| Ø (mm) | L 10 mm | L 11.5 mm | L 13 mm | Size A | Size B |
|---|---|---|---|---|---|
| Ø 2.9 | E2910 | E2911 | E2913 | 2.95 mm | 2.14 mm |
